| Name | Description |
|---|---|
| Height | 8.3m |
| Rated working voltage | 24Vdc |
| Rated working current | <10a |
| Low Voltage Protection | 22.8V(adjustable) |
| High Voltage Protection | 29V(adjustable) |
| Low voltage Reconnect | 25.2V(adjustable) |
| Solar Panel | 720W (16pcs x 45W mono-crystalline PERC solar panels) |
| Charge Controller(IoT) | 20A/24Vdc High eff. MPPT with dimming plan(can be monotored and controlled by cloud platform or APP) |
| LED | High power 100W /24Vdc |
| Decrative LED | 12 x LED Decrative Stickers(R/G/B) |
| Battery | 2x150Ah/12V Gel battery(Lithium/NiMH plan: 50Ah/24V) |
| Pole | 8.3 meters high, Hot- galvanizaton steel with Aluminum structure |
Remark: Lithium or NiMH battery plan is available, please contact with us.
