Name | Description |
---|---|
Height | 8.3m |
Rated working voltage | 24Vdc |
Rated working current | <10a |
Low Voltage Protection | 22.8V(adjustable) |
High Voltage Protection | 29V(adjustable) |
Low voltage Reconnect | 25.2V(adjustable) |
Solar Panel | 720W (16pcs x 45W mono-crystalline PERC solar panels) |
Charge Controller(IoT) | 20A/24Vdc High eff. MPPT with dimming plan(can be monotored and controlled by cloud platform or APP) |
LED | High power 100W /24Vdc |
Decrative LED | 12 x LED Decrative Stickers(R/G/B) |
Battery | 2x150Ah/12V Gel battery(Lithium/NiMH plan: 50Ah/24V) |
Pole | 8.3 meters high, Hot- galvanizaton steel with Aluminum structure |
Remark: Lithium or NiMH battery plan is available, please contact with us.
