| Name | Description |
|---|---|
| Height of Pole | 7 m |
| Light Source | 40W LED/24V with dimming function |
| Solar Panel | 300Wp Mono-Crystalline |
| Controller | Micro-processor MPPT Tracer over charging/discharging protection |
| Battery | 30AH/24V Lithium battery(dimming design) Maintenance-free, Lithium design |
| Signboard | 18W LED signboard |
| Lighting hours | 10-12 hours per day 2-3 backup days after full charging |
| Working temperature | -20 ℃- 60 ℃ |
| Material of Pole | hot-dip galvanized steel, powder coated |
Note:
1. Above design is based on sun radiation >4.5 kwh/㎡ and LED with dimming function
2. This design can be customized according to your requirements.
3. The battery can be changed with NiMH battery for long time service(anout 8 years)
| NiMH Plan with dimming design | |
| Solar panel | 300Wp Mono-crystalline |
| Battery | NiMH 30Ah/24V |
| Controller | MPPT or PWM |
