| Name | Description |
|---|---|
| Height of Pole | 8 m |
| Light Source | 30W LED/24V + 60W/24V with dimming function |
| Solar Panel | 400Wp Mono-Crystalline |
| Controller | Micro-processor MPPT Tracer over charging/discharging protection |
| Battery | 40AH/24V gel battery(dimming design can be 30Ah/24V) Maintenance-free, Pb-Carbon design |
| Lighting hours | 10-12 hours per day 2-3 backup days after full charging |
| Working temperature | -20 ℃- 60 ℃ |
| Material of Pole | hot-dip galvanized steel, powder coated |
Note:
1. Above design is based on sun radiation >4.5 kwh/㎡ and LED with dimming function
2. This design can be customized according to your requirements.
3. The battery can be changed with Lithium battery
| Gel battery Plan with dimming design | |
| Solar panel | 300Wp Mono-crystalline |
| Battery | Gel 100Ah/24V |
| Controller | MPPT or PWM |
