| Name | Description |
|---|---|
| Height of Pole | 5 m |
| Light Source | 40W LED/12V with dimming function |
| Solar Panel | 150Wp Mono-Crystalline |
| Controller | Micro-processor MPPT Tracer over charging/discharging protection |
| Battery | 120AH/12V gel battery(dimming design can be 80Ah/12V) Maintenance-free, Pb-Carbon design |
| Lighting hours | 10-12 hours per day 2-3 backup days after full charging |
| Working temperature | -20 ℃- 60 ℃ |
| Material of Pole | hot-dip galvanized steel, powder coated |
Note:
1. Above design is based on sun radiation >4.5 kwh/㎡ and LED with dimming function
2. This design can be customized according to your requirements.
3. The battery can be changed with Lithium battery
| Lithium Plan with dimming design | |
| Solar panel | 100Wp Mono-crystalline |
| Battery | Lithium 30Ah/12V |
| Controller | MPPT or PWM |
